Model

MTLJ2513C

 Table size

1200X700mm

 Spindle head

1~6 heads as per users' demand

Travel distance

X

2500mm

Y

1300mm

Z

200mm

Spindle

(OEM as per choice)

1#

HSD 6KW(13.5kw), 18000rpm Manual tool change

2#

HSD 8KW(12kw), 24000rpm 10 tool ATC

3#

Spindle + drilling block + mortiser + saw

Vacuum pump

5.5KW 150m³/h

Max. working Speed

X Y：30m/min； Z：15 m/min

Power

 26~33kw

Weight

6000~6500kgs
